| Jenis pembayaran: | T/T |
| Inkoterm: | FOB,CFR,CIF,EXW,FCA |
| Min. Memesan: | 1 |
| Transportasi: | Ocean,Land,Air |
| Pelabuhan: | ningbo,shanghai,guangzhou |
Model No: NBESRA300 - 000
Merek: basis baru
Jenis: mobil van
Bahan Bakar: Listrik
Asal: Cina
Applicable Compartment Volume: 7 - 10m³
Minimum Compartment Temperature: -20℃
Refrigerating Capacity: 3200W at 0℃/30℃ 1850W at -20℃/30℃
High Voltage: DC250V - DC450V (Low Voltage Platform) DC380V - DC750V (High Voltage Platform)
Power: 2500W at 0℃/+30℃ 1300W at -20℃/+30℃
Driving Mode: Pure Electric
Control Voltage: DC12V (9 ~ 16V) DC24V (16 ~ 32V)
Low - Voltage Power Supply: DC - DC Self - supply / or Connect to the Whole Vehicle
Standby Power Supply: AC220V/380V (Optional)
Kompresor: Guangzhou Guangyu Gy27.e72 - 601c (Inverter)
Pendingin: R404a
Biaya Refrigeran: 1.2kg
Metode Pencairan: Pencairan gas panas otomatis
Metode Pemanas: Pemanasan gas panas / PTC (opsional)
Metode Kontrol: Dapat komunikasi
Perakitan Kondensor: Dimensi (l*w*h) (mm): 740*730*468, berat (kg): 75
Kipas Kondensor: Kuantitas (PC): 1, volume udara total (m³/h): 1800
Perakitan Evaporator: Dimensi (l*w*h) (mm): 1038*570*140, berat (kg): 22
Penggemar Evaporator: Kuantitas (PC): 2, total volume udara (m³/jam): 2000
| Tipe paket | : | Karton dan kotak kayu |
| Contoh pada gamba | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Local Scenario | Pain Points | Our Solution |
| Durian Season Cold Chain |
- Pahang’s Cat Mountain King (60% global production) needs 24-hour sorting/-196℃ freezing;
- Small-batch, high-frequency delivery to airports.
|
- Precision temp control for post-harvest preservation;
- Compact design for agile transport to airports.
|
| Pharmaceutical Park (Iskandar Puteri, Johor) |
- Urgent demand for -18℃±0.5℃ precision for vaccines/biologics;
- Proximity to Singapore requires timeliness.
|
- Pharmaceutical cold chain vehicle with ±0.5℃ accuracy;
- 20-minute fast cooling for emergency deliveries.
|
| Green Logistics Policy |
- Malaysia’s 2050 carbon neutral goal;
- Need for eco-friendly electric refrigerated van Malaysia.
|
- Zero-emission new energy system + solar supplement;
- Compliant with national green logistics strategies (supports truk sejuk Malaysia sustainability).
|
| Urban Delivery (Kuala Lumpur, Johor Bahru) |
- Traffic congestion limits large reefer truck Malaysia efficiency;
- Narrow streets need agile chiller van Malaysia.
|
- Compact refrigerated mini truck for last-mile navigation;
- Multi-temp zones for F&B/retail small-batch deliveries.
|
| Feature | Newbase Modular Refrigerated Mini Truck | Traditional Refrigerated Lorry Malaysia |
| Urban Fit | Compact for KL/Johor’s narrow streets—ideal chiller van Malaysia for last mile | Bulky—inefficient for small-batch urban delivery |
| Payload | 1.2 tons (matches Malaysian SMEs’ needs) | 5-50 tons (overkill for most B2B shipments) |
| Temperature Control | -20°C to +25°C, ±0.5°C precision | Narrow range (-15°C to +5°C), ±1-2°C precision |
| Eco-Friendliness | Zero-emission + solar power (aligns with green policies) | High carbon emissions—non-compliant with sustainability goals |
| Cost-Effectiveness | Lower upfront investment + energy savings (best for small business) | High fuel/ maintenance costs |
| Smart Tech | Real-time IoT monitoring (4G-compatible) | Basic/no monitoring—delayed data or manual logs |
